Advanced Gmail

A Gmail MCP server for Claude Code that provides full email management across multiple Gmail accounts.

Features

• 12 tools: list, search, read, thread, labels, send, draft, reply, archive, label, trash, batch modify
• Multi-account support with simple aliases
• OAuth2 authentication with interactive CLI flow
• Token auto-refresh — re-authenticates transparently
• Rate limit retry with exponential backoff
• Claude Code commands included (/email and /checkemail) for structured inbox triage

Quick Start

1. Clone & Install

git clone https://github.com/coreyepstein/advanced-gmail-mcp.git
cd advanced-gmail-mcp
npm install

2. Google Cloud Setup

1. Go to Google Cloud Console
2. Create a new project (or select an existing one)
3. Enable the Gmail API:
   • APIs & Services → Enable APIs → search "Gmail API" → Enable
4. Configure the OAuth consent screen:
   • APIs & Services → OAuth consent screen
   • User type: External (or Internal if using Google Workspace)
   • Add your email address(es) as test users
   • Add scopes: gmail.readonly, gmail.modify, gmail.send, gmail.compose
5. Create OAuth credentials:
   • APIs & Services → Credentials → Create Credentials → OAuth client ID
   • Application type: Desktop app
   • Download the JSON file
6. Save the downloaded file as credentials.json in the project root

3. Configure Accounts

cp accounts.example.json accounts.json

Edit accounts.json with your Gmail accounts:

{
  "accounts": [
    { "email": "[email protected]", "alias": "personal" },
    { "email": "[email protected]", "alias": "work" }
  ],
  "default": "personal"
}

You can add as many accounts as you want. Each needs a unique alias.

4. Authenticate

# Authenticate all accounts (opens browser for each)
npm run auth

# Or authenticate a single account
npm run auth -- work

# Check auth status
npm run auth:check

The auth flow opens a browser window for each account. Tokens are saved to ./tokens/.

5. Add to Claude Code

Add to your MCP config (project .mcp.json or ~/.claude.json):

{
  "mcpServers": {
    "gmail": {
      "type": "stdio",
      "command": "npx",
      "args": ["tsx", "/absolute/path/to/gmail-mcp/src/server.ts"]
    }
  }
}

Important: Use the absolute path to src/server.ts.

6. (Optional) Add Commands

Copy the included Claude Code commands for structured email workflows:

# From your project root (where .claude/ lives)
mkdir -p .claude/commands
cp /path/to/gmail-mcp/.claude/commands/email.md .claude/commands/
cp /path/to/gmail-mcp/.claude/commands/checkemail.md .claude/commands/

Then use /email or /checkemail in Claude Code.

Tools

Tool	Description
list_emails	List inbox or label emails
search_emails	Search with Gmail query syntax
read_email	Read full email by ID
get_thread	Get full thread with all messages
get_labels	List all labels
send_email	Send a new email
draft_email	Create a draft
reply_email	Reply with proper threading
archive_email	Archive (remove INBOX label)
label_email	Add/remove labels
trash_email	Move to trash
batch_modify	Batch archive/trash/label

All tools accept an optional account parameter (alias or email). Defaults to the account set in accounts.json.

Commands

/email [action] [account]

Full email management command with actions:

• triage — Summarize inbox, batch archive/trash
• cleanup — 4-phase daily email workflow
• search {query} — Cross-account search
• send / draft / reply — Compose with confirmation

/checkemail [account]

Quick 3-phase inbox sweep:

1. Fetch & classify all inbox emails (auto-archive junk)
2. Batch archive on approval
3. Walk through remaining emails one at a time

Troubleshooting

Error	Fix
accounts.json not found	Copy accounts.example.json to accounts.json
credentials.json not found	Download OAuth credentials from GCP Console
No token for...	Run npm run auth -- <alias>
Token refresh failed	Re-authenticate: npm run auth -- <alias>
403 Forbidden	Add your email as test user in GCP OAuth consent screen
403 insufficient scopes	Re-authenticate to get updated scopes

License

MIT
