NCM Servers Suite

A suite of three focused MCP (Model Context Protocol) servers for the Ericsson Enterprise Wireless NCM API, split by domain responsibility for optimal LLM tool selection.

Architecture

Server	Port	Domain	Tools
ncm-fleet	3001	Routers, groups, accounts, locations, configurations, firmware, products	17
ncm-monitoring	3002	Net devices, alerts/logs, speed tests	6
ncm-cloud-services	3003	Users, subscriptions, private cellular, exchange	13

All servers default to Streamable HTTP transport and run together in a single container.

Quick Start

1. Install

cd ncm_mcp_servers
pip install -e .

2. Configure Credentials

Copy the example and fill in your values:

cp credentials.example.json credentials.json

{
    "X_CP_API_ID": "your-cp-api-id",
    "X_CP_API_KEY": "your-cp-api-key",
    "X_ECM_API_ID": "your-ecm-api-id",
    "X_ECM_API_KEY": "your-ecm-api-key",
    "NCM_API_TOKEN": "your-v3-bearer-token"
}

Alternatively, set environment variables with the same names.

3. Run (Docker — recommended)

docker compose up --build

Or build and run manually:

docker build -t ncm-mcp-servers .
docker run -p 3001:3001 -p 3002:3002 -p 3003:3003 \
  -v ./credentials.json:/app/credentials.json:ro \
  ncm-mcp-servers

This starts a single container running all 3 servers:

• http://localhost:3001/mcp — ncm-fleet
• http://localhost:3002/mcp — ncm-monitoring
• http://localhost:3003/mcp — ncm-cloud-services

4. Run (Local, without Docker)

# Run all 3 servers in a single process (recommended for local dev)
ncm-mcp-servers

# Or via python module
python -m ncm_mcp_servers

Run servers individually if you only need a subset:

ncm-fleet            # port 3001
ncm-monitoring       # port 3002
ncm-cloud-services   # port 3003

Override ports via environment variables:

NCM_FLEET_PORT=4001 ncm-fleet
NCM_MONITORING_PORT=4002 ncm-monitoring
NCM_CLOUD_SERVICES_PORT=4003 ncm-cloud-services

5. Transport Options

The default transport is Streamable HTTP. Supported transports:

Transport	Value	Use case
Streamable HTTP	streamable-http (default)	Recommended for all MCP clients
SSE	sse	Legacy MCP clients using Server-Sent Events
Stdio	stdio	Piped MCP clients (single server only)

# Use SSE transport (legacy)
MCP_TRANSPORT=sse ncm-mcp-servers

# Use stdio (only works with individual servers, not the unified runner)
MCP_TRANSPORT=stdio ncm-fleet

MCP Client Configuration

Add to your MCP settings (e.g. .kiro/settings/mcp.json):

{
  "mcpServers": {
    "ncm-fleet": {
      "url": "http://localhost:3001/mcp"
    },
    "ncm-monitoring": {
      "url": "http://localhost:3002/mcp"
    },
    "ncm-cloud-services": {
      "url": "http://localhost:3003/mcp"
    }
  }
}

Tool Consolidation Strategy

CRUD operations are consolidated into manage_* tools with an action parameter:

manage_router(action="rename", router_id=123, new_name="foo")
manage_router(action="delete", router_id=123)
manage_router(action="update", router_id=123, description="bar")

Read-only metrics are consolidated by type:

get_net_device_metrics(metric_type="signal", net_device=1)
get_net_device_metrics(metric_type="usage", net_device=1)
get_net_device_metrics(metric_type="wan", net_device=1)
get_net_device_metrics(metric_type="modem", net_device=1)

Project Structure

ncm_mcp_servers/
├── pyproject.toml
├── Dockerfile
├── docker-compose.yml
├── entrypoint.sh
├── credentials.example.json
├── credentials.json          # Your credentials (gitignored)
├── ncm_mcp_servers/
│   ├── shared/               # Common utilities
│   │   ├── ncm.py            # NCM API client library
│   │   ├── credentials.py    # Credential loading
│   │   ├── error_handler.py  # Response/error formatting
│   │   └── client.py         # NCM client factory
│   ├── ncm_fleet/            # Fleet management server (port 3001)
│   │   ├── server.py
│   │   └── tools/
│   │       ├── routers.py
│   │       ├── groups.py
│   │       ├── accounts.py
│   │       ├── locations.py
│   │       ├── configurations.py
│   │       └── firmware.py
│   ├── ncm_monitoring/       # Monitoring server (port 3002)
│   │   ├── server.py
│   │   └── tools/
│   │       ├── net_devices.py
│   │       ├── alerts.py
│   │       └── speed_tests.py
│   └── ncm_cloud_services/   # Cloud services server (port 3003)
│       ├── server.py
│       └── tools/
│           ├── users.py
│           ├── subscriptions.py
│           ├── private_cellular.py
│           └── exchange.py
└── README.md

Tool Reference

ncm-fleet (17 tools)

Tool	Description
get_routers	Query routers by ID, name, account, or group
manage_router	Rename, delete, update fields, assign to group/account, remove from group
reboot_router	Reboot a single router
reboot_group	Reboot all routers in a group
get_groups	Query groups by ID, name, or account
manage_group	Create, rename, delete, update groups
get_accounts	Query accounts by ID or name
manage_subaccount	Create, rename, delete subaccounts
get_locations	Query current or historical locations
manage_location	Create or delete router locations
get_configuration_managers	Query config sync status
patch_config	Partial config update (router or group)
put_router_config	Full config replacement
copy_router_config	Copy config between routers
resume_updates	Resume suspended config sync
get_firmware	Query firmware versions by product
get_products	Query product catalog

ncm-monitoring (6 tools)

Tool	Description
get_net_devices	Query net devices by router, mode, connection state
get_net_device_health	Get cellular health scores
get_net_device_metrics	Signal, usage, WAN, or modem metrics
get_logs	Alerts, recent alerts, router logs, or activity logs
create_speed_test	Run speed test on devices or all modems on a router
get_speed_test	Get speed test status and results

ncm-cloud-services (13 tools)

Tool	Description
get_users	Query NCM users
manage_user	Create, update, delete users, change role
get_subscriptions	Query subscriptions
manage_subscription	Regrade or unlicense devices
get_networks	Query private cellular networks
manage_network	Create, update, delete networks
get_radios	Query radios and operational status
manage_radio	Update radio settings
manage_sim	Query or update SIMs
get_exchange_sites	Query exchange sites
manage_exchange_site	Create, update, delete sites
get_exchange_resources	Query exchange resources
manage_exchange_resource	Create, update, delete resources
