Altium Schematic Parser

Read Altium Designer schematic files (.SchDoc) without Altium installed.

Extracts components, nets, pins, ports, and hierarchy into JSON or Markdown. Works as a command-line tool or as an MCP server so VS Code Copilot / Claude can answer questions about your schematics.

What problem does this solve?

Altium .SchDoc files are binary. You can't open them in a text editor, and you need an Altium license to view them. This tool reads the binary format directly and gives you the data in a usable form.

Requirements

• Python 3.10 or newer
• No Altium license required

Installation

git clone https://github.com/brandons-cs/altium-schdoc-mcp.git
cd altium-schdoc-mcp
python -m venv .venv

Activate the virtual environment:

# Windows (PowerShell)
.venv\Scripts\activate

# Windows (cmd)
.venv\Scripts\activate.bat

# Linux / macOS
source .venv/bin/activate

Install the tool:

pip install -e .

To also use the MCP server (for VS Code Copilot / Claude):

pip install -e ".[mcp]"

CLI Usage

Parse a single file:

# Print JSON to terminal
parse-schdoc path/to/schematic.SchDoc

# Save JSON to a file
parse-schdoc path/to/schematic.SchDoc -o output.json

# Print Markdown to terminal
parse-schdoc path/to/schematic.SchDoc --markdown

# Save Markdown to a file
parse-schdoc path/to/schematic.SchDoc --markdown -o output.md

Parse all .SchDoc files in a folder:

parse-schdoc --batch path/to/schematics/ --markdown -o path/to/output/

MCP Server (VS Code / Claude)

The MCP server lets an AI assistant read your schematics on demand. You don't need to pre-parse anything — the assistant calls the tool when it needs the data.

Setup

Create a file called .vscode/mcp.json in your project:

{
    "servers": {
        "altium-schdoc": {
            "type": "stdio",
            "command": "C:/Projects/altium-schdoc-mcp/.venv/Scripts/python.exe",
            "args": ["-m", "src.mcp_server"],
            "cwd": "C:/Projects/altium-schdoc-mcp"
        }
    }
}

Replace the command path with the actual path to your Python executable inside the .venv.

Reload VS Code after saving the file. The MCP server will appear in the Copilot tools list.

Available Tools

Tool	What it does
parse_schdoc_json	Returns all schematic data as JSON
parse_schdoc_markdown	Returns a readable summary (tables, net lists)
list_schematics	Lists .SchDoc files in a folder
search_component	Finds components by designator, value, or description
get_net_connections	Shows which pins are connected to a given net

Example questions you can ask Copilot

• "What components are on the E-Stop Safety schematic?"
• "Which pins are connected to the 24VDC net?"
• "List all relay designators in the DUT 1 IO schematic"
• "What is the footprint for Rly301?"

What you get

JSON output

{
  "metadata": {
    "filename": "E-Stop Safety Section.SchDoc",
    "parser_version": "0.1.0"
  },
  "components": [
    {
      "designator": "Rly202",
      "library_reference": "WAGO - Relay, 788-312",
      "description": "24V 2CO 8A Safety Relay and Base",
      "footprint": "",
      "value": "788-312",
      "parameters": {"Value": "788-312"},
      "pins": [
        {"designator": "A1", "name": "A1", "electrical": "Passive"},
        {"designator": "11", "name": "11", "electrical": "Passive"}
      ]
    }
  ],
  "nets": {
    "E-Stop 1(1)": ["Rly201.A1", "[Port]E-Stop 1(1)"],
    "E-Stop Rst (3)": ["Rly202.A2", "Rly202.14", "Rly203.14"]
  },
  "pins": [],
  "ports": [
    {"name": "E-Stop 1(1)", "io_type": "Bidirectional", "x": 100.0, "y": 200.0}
  ],
  "power_ports": [],
  "hierarchy": []
}

Markdown output

The Markdown output contains:

• Component table with designator, library reference, value, footprint, and description
• Power rails (GND, VCC, etc.) with their symbol styles
• Ports (connections between schematic sheets)
• Net list showing which component pins are connected to each net
• Pin map listing every pin on every component
• Sheet hierarchy if the schematic references child sheets

How it works

Altium .SchDoc files are OLE2 compound documents (the same container format as old .doc files). Inside, the FileHeader stream contains all schematic objects as length-prefixed, pipe-delimited key-value records.

Each record has a RECORD field that identifies its type:

Record ID	Type	What it contains
1	Component	Library reference, description, part count
2	Pin	Name, designator, electrical type, position
15	Sheet Symbol	Child sheet reference
16	Sheet Entry	Port name and IO direction on a sheet symbol
17	Power Port	Named power rail (GND, VCC, etc.)
18	Port	Inter-sheet connection point
25	Net Label	Named net at a specific position
27	Wire	Coordinates of wire segments
29	Junction	Wire merge point
34	Designator	Component reference designator (R1, U3, etc.)
41	Parameter	Component parameters (value, comment, etc.)
45	Implementation	Footprint / model reference

Child records (pins, designators, parameters) link to their parent component via OWNERINDEX, which is the 0-based position of the parent in the record stream (counting from records[1]).

Net connectivity is resolved by:

1. Collecting all wire segments and building a union-find graph on their endpoints
2. Calculating pin connection points from body position + pin length in the rotation direction
3. Snapping pins, net labels, power ports, and ports to the nearest wire endpoint (within ±2 units)
4. Grouping connected pins under the net name assigned by labels, power ports, or ports

Limitations

• Coordinate-based net resolution — pins snap to wire endpoints within ±2 Altium units. Non-standard placements may cause missed connections.
• Per-sheet only — each .SchDoc is parsed independently. Cross-sheet net tracing (via the .PrjPCB project file) is not yet supported.
• Data only — no visual rendering. Use Altium 365 or Altium Designer to view the schematic graphically.
• Tested with Altium Designer v20–v24 — older or newer versions may have undocumented record types.

License

MIT — see LICENSE.
