Oxidized

MCP server for Oxidized - network device configuration backup tool.

Exposes Oxidized data as MCP tools and resources so that LLM assistants can query, compare, analyse, and download network device configurations via natural language.

Features

Capability	Description
list_devices	List all devices managed by Oxidized
find_devices	Find devices by exact or partial name, full name, or IP address
get_device_status	Show backup status and last run details for a device
get_device_versions	List all stored configuration versions for a device
prepare_config	Select a device for the static current-config resource
oxidized://config/get_content	Download the current configuration prepared by prepare_config
prepare_blame	Select a device for the static blame resource
oxidized://config/get_blame	Download the annotated configuration prepared by prepare_blame
get_config_with_inline_diff	Show current config with inline change markers vs a reference version
get_diff_between_versions	Unified diff between two historical versions with configurable context lines

All device-specific tools accept an exact device name or a unique partial name. Matching is case-insensitive. If a partial name matches multiple devices, the server returns the matching candidates and asks for a more specific name or group instead of calling Oxidized with an ambiguous device name.

Prepared configuration resources

Some configurations and blame results are too large for a tool response. Use the prepare tools to resolve a device and then read the associated static resource. The prepare tools return only device metadata and do not load configuration data.

prepare_config(node="router01", group="Core")
read oxidized://config/get_content

prepare_blame(node="switch02")
read oxidized://config/get_blame

The server stores only the resolved node and group in memory for the current MCP session. Current-config and blame selections are separate, so both resources can refer to different devices in the same session. Resource reads fetch the current configuration and all required historical versions live from Oxidized. No configuration, version, or blame result is cached or written to a database.

If a resource is read before its matching prepare tool, it returns instructions for the required prepare call. A server restart clears all prepared selections. Run one server worker because prepared selections are intentionally held only in that process memory.

Requirements

• Python 3.11+
• Oxidized with oxidized-web running (REST API enabled)
• Docker (recommended)

Quick Start

cp .env.example .env
# Edit .env with your Oxidized URL and credentials
docker compose up -d

The MCP server listens on port 8000 (Streamable HTTP transport).

Configuration

Variable	Description	Default
OXIDIZED_URL	Base URL of your Oxidized instance	required
OXIDIZED_USER	Basic Auth username	required
OXIDIZED_PASS	Basic Auth password	required
MCP_PORT	Port the MCP server listens on	8000

MCP Client Configuration

Add to your MCP client (e.g. Claude Desktop mcp.json):

{
  "mcpServers": {
    "oxidized": {
      "url": "http://localhost:8000/mcp"
    }
  }
}

Example Prompts

• "List all devices and show me which ones failed their last backup."
• "Find the device containing HFGBF253 in its name."
• "Show the status of the device matching 253-IT."
• "List all stored versions for HFGBF253-IT in the Firewalls group."
• "Prepare the current configuration of router01 for download."
• "Prepare configuration blame for switch02."
• "Show the current config of switch02 and highlight all changes compared to version 12."
• "Show the diff between version 12 and version 14 for firewall01 with 10 lines of context."

Development

pip install -e ".[dev]"
python -m mcp_oxidized.server

License

MIT
