依赖 / Dependency：https://github.com/BEK-Group/MindustryX

用于通过本机 AI bridge 控制 MindustryX 的 MCP 服务器。

环境要求

• Node.js 20+
• 带 AI bridge 的 MindustryX 桌面 jar

本 MCP 服务器会自动读取桥接文件并连接，使用者不需要手动填写端口。

MindustryX jar 是外部产物，不提交到本仓库。

默认 jar 路径：

artifacts/MindustryX-MCP-no-render.jar
artifacts/MindustryX-MCP-render.jar

也可在 launch_client 中传入 jarPath，或设置环境变量：

MINDUSTRYX_MCP_NO_RENDER_JAR
MINDUSTRYX_MCP_RENDER_JAR

安装

npm install
npm run build
npm start

建立连接

AI 使用流程

1. 启动本 MCP 服务器，或让 MCP 客户端通过以下配置启动：

{
  "mcpServers": {
    "mindustry": {
      "command": "node",
      "args": [
        "<path-to-Mindustry-MCP>/dist/index.js"
      ]
    }
  }
}

2. 调用 launch_client 工具。
   • 默认：启动 MindustryX-MCP-no-render.jar。
   • 需要可见窗口调试时传 mode: "render"。
3. 调用 get_state 验证桥接。
4. 用 load_map 载入本地地图，或用 join_game 让 X 端连接服务器。
5. 使用完由 MCP 拉起的客户端后，调用 close_client。

MCP prompt mindustry_client_usage 也提供同样的 AI 使用提示。

手动流程

也可以先手动启动 MindustryX AI bridge jar，再使用本 MCP server：

1. 双击打开一个 MindustryX AI bridge jar。
   • MindustryX-MCP-render.jar：带渲染的普通桌面客户端。
   • MindustryX-MCP-no-render.jar：默认关闭世界/UI 渲染的桌面客户端。 手动构建产物位于 artifacts/。
2. 等 MindustryX 启动完成，桥接文件会出现在 %TEMP%\mindustryx-ai-bridge\bridge-info.json。

连接后可先调用 get_state 验证桥接，再用 load_map 载入本地地图，或用 join_game 让 X 端连接服务器。

工具

• 客户端：launch_client、close_client
• 读取：get_state、list_maps、get_tiles、get_buildings、get_units、get_content
• 写入：load_map、join_game、leave_game、place_block、break_block、write_logic、spawn_unit、set_speed、pause
• 工具：await_op

持续集成

仓库已包含 CI 工作流，会在每次 push 和 pull request 时运行 npm ci 和 npm run build。

源码 fork：https://github.com/BEK-Group/MindustryX

---

Mindustry MCP Server

Dependency: https://github.com/BEK-Group/MindustryX

MCP server for controlling MindustryX through its local AI bridge.

Requirements

• Node.js 20+
• A MindustryX desktop jar built with the AI bridge

The X client starts a local TCP bridge on 127.0.0.1 and writes connection metadata to:

%TEMP%\mindustryx-ai-bridge\bridge-info.json

This MCP server reads that file and connects automatically. Users do not need to enter the port manually.

The MindustryX jars are external artifacts. They are not committed to this repository.

Default jar paths:

artifacts/MindustryX-MCP-no-render.jar
artifacts/MindustryX-MCP-render.jar

You can also pass jarPath to launch_client, or set:

MINDUSTRYX_MCP_NO_RENDER_JAR
MINDUSTRYX_MCP_RENDER_JAR

Install

npm install
npm run build
npm start

Connect

AI workflow

1. Start this MCP server, or let your MCP client launch it with:

{
  "mcpServers": {
    "mindustry": {
      "command": "node",
      "args": [
        "<path-to-Mindustry-MCP>/dist/index.js"
      ]
    }
  }
}

2. Call the launch_client tool.
   • Default: starts MindustryX-MCP-no-render.jar.
   • Use mode: "render" when a visible client is needed for debugging.
3. Call get_state to verify the bridge.
4. Use load_map to enter a local map, or join_game to connect the X client to a server.
5. When done with a client launched by this MCP server, call close_client.

The MCP prompt mindustry_client_usage contains the same AI-facing workflow for clients that expose prompts.

Manual workflow

You can still start a MindustryX AI bridge jar manually before using this MCP server:

1. Double-click one of the MindustryX AI bridge jars.
   • MindustryX-MCP-render.jar: normal desktop client with rendering.
   • MindustryX-MCP-no-render.jar: desktop client with world/UI rendering disabled by default. Manual build outputs are placed in artifacts/.
2. Wait until MindustryX finishes startup. The bridge file should appear at %TEMP%\mindustryx-ai-bridge\bridge-info.json.

After connection, use get_state to verify the bridge. Use load_map to enter a local map, or join_game to connect the X client to a server.

Tools

• Client: launch_client, close_client
• Read: get_state, list_maps, get_tiles, get_buildings, get_units, get_content
• Write: load_map, join_game, leave_game, place_block, break_block, write_logic, spawn_unit, set_speed, pause
• Utility: await_op

GitHub Actions

The repository includes a CI workflow that runs npm ci and npm run build on every push and pull request.

MindustryX fork: https://github.com/BEK-Group/MindustryX
