Cloudera

MCP (Model Context Protocol) server for the Cloudera Manager REST API. Designed for the multi-agent log analysis and operations platform running on Cloudera Public Cloud / CDP.

The server exposes CM capabilities as MCP tools so that agents built in Cloudera Agent Studio can extract logs, retrieve alerts, read and modify configurations, restart services, and manage the CM registry — all through a single, consistent interface.

---

Table of contents

1. Architecture
2. Project structure
3. Prerequisites
4. Installation
5. Configuration
6. Running locally
7. Deployment in Cloudera Agent Studio
8. Exposed tools
9. CM registry (Iceberg table)
10. Security notes

---

Architecture

Cloudera Agent Studio
        │
        │  MCP (stdio)
        ▼
┌─────────────────────────┐
│   cloudera-manager-mcp  │
│                         │
│  server.py              │  tool dispatch
│  ├── cm_pool.py         │  HTTP client pool (one per CM)
│  ├── cm_client.py       │  CM REST API calls (httpx + tenacity)
│  ├── cm_registry.py     │  Iceberg registry via Impala / HiveServer2
│  ├── config.py          │  settings from environment variables
│  └── models.py          │  Pydantic I/O models
└────────────┬────────────┘
             │  HTTPS / REST API
             ▼
   Cloudera Manager instances
   (one per DataHub environment)
             │
             │  reads / writes
             ▼
   Iceberg table — cdp_registry.cloudera_managers
   (Impala or HiveServer2)

CM instances are not configured in environment variables. They are stored in an Iceberg table and loaded at startup. The only variables in .env are the Impala / HiveServer2 connection parameters needed to read that table.

---

Project structure

cloudera-mcp-server/
├── pyproject.toml                       package metadata, dependencies, entry point
├── env.example                          environment variable template
├── agent_studio_mcp.json                Agent Studio MCP server configuration
├── requirements.txt                     pip-compatible dependency list
├── docs/
│   └── registry_table.sql               DDL for the Iceberg registry table
└── src/
    └── cloudera_manager_mcp/
        ├── __init__.py
        ├── server.py                    MCP server entry point, tool definitions and dispatch
        ├── cm_client.py                 async HTTP client for CM REST API
        ├── cm_pool.py                   multi-CM connection pool, cluster → host resolution
        ├── cm_registry.py               Iceberg registry (Impala / HiveServer2 via impyla)
        └── config.py                    Pydantic settings (ImpalaSettings, ServerSettings)

---

Prerequisites

Requirement	Version
Python	3.11 or later
uv	0.4 or later — install
Cloudera Manager	7.x (CDP 7.1.7+)
Impala or HiveServer2	any version that supports Iceberg v2
CM user role	Cluster Administrator or higher

---

Installation

# Clone the repository
git clone https://github.com/dvergari/cloudera-mcp-server.git
cd cloudera-mcp-server

# Create the virtual environment and install all dependencies
uv sync

# Copy and edit the environment configuration
cp env.example .env
$EDITOR .env

uv sync reads pyproject.toml, resolves the dependency graph, creates .venv/ in the project root, and installs everything. No manual pip install step is needed.

---

Configuration

All configuration is done through environment variables, loaded from .env at startup. See .env.example for the full reference with inline documentation.

Variable groups

Prefix	Purpose
MCP_*	Server behaviour — log level, concurrency limits, retry policy
IMPALA_*	SQL backend for the CM registry Iceberg table

SQL backend selection

The server supports two backends for reading the Iceberg registry table, both accessed through impyla:

IMPALA_BACKEND	Default port	Kerberos service
impala	21050	impala
hiveserver2	10000	hive

Setting IMPALA_BACKEND=hiveserver2 is sufficient to switch backends. The port and Kerberos service name are resolved automatically from the backend unless overridden explicitly.

Minimal .env for development (Impala, no TLS)

MCP_LOG_LEVEL=DEBUG
IMPALA_BACKEND=impala
IMPALA_HOST=impala-dev.example.com
IMPALA_AUTH_MECHANISM=PLAIN
IMPALA_USE_SSL=false
IMPALA_DATABASE=cdp_registry
IMPALA_TABLE=cloudera_managers

Minimal .env for production (HiveServer2, LDAP, TLS)

MCP_LOG_LEVEL=INFO
IMPALA_BACKEND=hiveserver2
IMPALA_HOST=hs2-prod.example.com
IMPALA_AUTH_MECHANISM=LDAP
IMPALA_USERNAME=svc-mcp-agent
IMPALA_PASSWORD=<password>
IMPALA_USE_SSL=true
IMPALA_DATABASE=cdp_registry
IMPALA_TABLE=cloudera_managers
IMPALA_REFRESH_INTERVAL_SECS=300

---

Running locally

# Run directly with uv (recommended)
uv run cloudera-manager-mcp

# Or activate the virtualenv first
source .venv/bin/activate
cloudera-manager-mcp

The server starts and listens on stdio (standard input / output)

---

Deployment in Cloudera Agent Studio

The agent_studio_mcp.json file contains ready-to-use configuration blocks for three deployment modes. Copy the relevant block into Agent Studio → Settings → MCP Servers.

Mode A — local checkout (development)

Uses uv --directory to run the server in-place. No build step required; uv manages the virtualenv automatically.

{
  "command": "uv",
  "args": [
    "--directory", "/path/to/cloudera-mcp-server-en",
    "run", "cloudera-manager-mcp"
  ],
  "env": { "IMPALA_HOST": "...", "..." : "..." }
}

Mode B — Git repository (staging / CI)

Uses uvx --from git+https://... to install and run in a single step. Replace the URL with your internal GitLab or GitHub repository.

{
  "command": "uvx",
  "args": [
    "--from", "git+https://github.com/dvergari/cloudera-mcp-server.git",
    "cloudera-manager-mcp"
  ],
  "env": { "IMPALA_HOST": "...", "..." : "..." }
}

Mode C — local wheel (air-gapped / production)

Build the wheel once, copy it to the Agent Studio host in path /home/cdsw/agent-studio/.local/share/mcp, then point uvx at the sandboxed path. No network access required at runtime.

# Build
uv build
# → dist/cloudera_manager_mcp-1.0.0-py3-none-any.whl

# Copy to the Agent Studio host, then configure:

{
  "command": "uvx",
  "args": [
    "--from", "/home/cdsw/.local/share/uv/mcp/cloudera_manager_mcp-1.0.0-py3-none-any.whl",
    "cloudera-manager-mcp"
  ],
  "env": { "IMPALA_HOST": "...", "..." : "..." }
}

---

Exposed tools

CM operational tools

Tool	Description
get_service_logs	Extract logs from a service (YARN, HDFS, Solr, Spark, Hive…) with filters for host, role type, log level, and keyword
get_alerts	Fetch CM health alerts filtered by cluster, severity, service, and time range
get_service_metrics	Retrieve time-series metrics using CM metric names (cpu_percent, jvm_heap_used_mb…)
get_config	Read service or role-config-group configuration; view=full includes defaults
update_config	Modify a single CM configuration parameter; always returns old_value for verification
run_service_command	Start / stop / restart / rollingRestart a service — async, returns command_id
get_command_status	Poll the status of a running CM command by command_id
get_host_status	Health status of cluster hosts: health summary, resources, active roles
get_audit_events	CM audit log entries: logins, config changes, service operations
list_datahubs	Enumerate DataHub clusters with status, services, node count, cloud provider
list_clusters	List all clusters managed by every configured CM instance
list_services	List services in a specific cluster
refresh_cluster_map	Rebuild the internal cluster → CM host lookup table

Registry management tools

Tool	Description
registry_list	List all CM instances stored in the Iceberg table (passwords excluded)
registry_stats	Aggregate statistics: total CMs, active count, environments, cloud providers
registry_add	Register a new CM; immediately adds it to the connection pool
registry_deactivate	Soft-delete a CM (active=FALSE); row is preserved for audit history
registry_update_field	Update a single field (port, api_version, timeout…) for a given CM host
registry_reload	Force a registry cache reload from Iceberg and refresh the connection pool

---

CM registry (Iceberg table)

CM instances are stored in the Iceberg table cdp_registry.cloudera_managers. The full DDL, sample data, and common update operations are in docs/registry_table.sql.

To create the table and insert the first records:

impala-shell -f docs/registry_table.sql

The server reads the table at startup and caches the results in memory. The cache is refreshed every IMPALA_REFRESH_INTERVAL_SECS seconds (default 300). To force an immediate reload without restarting the server, call the registry_reload tool.

---

Security notes

• CM credentials are stored only in the Iceberg registry table, never in environment variables or config files.
• Passwords in the registry table are currently stored in plaintext. For production deployments, integrate cryptography.Fernet or a cloud secrets manager (AWS Secrets Manager, Azure Key Vault, GCP Secret Manager) at the cm_registry.load() call site.
• Tool output never includes CM passwords. The registry_list tool explicitly excludes the password column from its SELECT statement.
• Sensitive CM config parameters (sensitive=true) are passed through without being logged by the server.
• Destructive tools (update_config, run_service_command, registry_deactivate) should be gated by an agent-level confirmation step before the tool is actually called. This is enforced at the agent prompt level, not at the server level.
• Use a dedicated CM service account (svc-mcp-agent) with the minimum required permissions rather than the admin user.
