MCPGen

Generate secure, policy-aware MCP servers from OpenAPI specs.

MCPGen is a production-oriented MVP Python framework that turns OpenAPI specifications into safe-by-default tool servers. It can generate a FastAPI demo server or an MCP-style stdio server, while keeping write operations blocked unless future policy work explicitly enables them.

Problem

AI applications often need access to many APIs, databases, and internal systems. Without a framework, teams tend to rebuild the same integrations repeatedly, expose too many tools to the model, and skip safety controls such as risk classification, audit logs, and write-operation guardrails.

MCP servers make tools available to AI systems, but fast prototypes can accidentally expose dangerous operations like DELETE, POST, PATCH, or PUT without review.

Solution

MCPGen reads an OpenAPI YAML or JSON file and generates:

• structured tool descriptors
• safe exposed tool lists
• withheld tool reports
• input schemas
• a policy-aware FastAPI or MCP server
• dry-run previews
• safe GET execution
• JSONL audit logs
• file-based runtime metrics
• semantic tool routing with keyword fallback

The default behavior is intentionally conservative: only low-risk GET tools are exposed.

Features

• OpenAPI YAML/JSON parsing
• Tool generation from endpoints
• Risk classification:
  • GET = low
  • POST, PUT, PATCH = medium
  • DELETE = high
• Safe-by-default filtering
• Input schema generation from path/query parameters and JSON request bodies
• Semantic tool routing with keyword fallback
• FastAPI mode
• MCP stdio mode with tools/list and tools/call
• Dry-run request previews
• Safe real execution for low-risk GET tools only
• Central policy engine
• JSONL audit logging
• Runtime metrics for routing, policy decisions, dry-runs, execution outcomes, and latency
• Upstream auth passthrough and API key injection without hardcoded secrets
• CLI commands: generate, inspect
• Config via mcpgen.yaml

Architecture Flow

OpenAPI spec
  -> parser
  -> tool generator
  -> risk classifier
  -> safety filter
  -> tools.json / tools.all.json / tools.embeddings.json / safety_report.json
  -> generated FastAPI or MCP server
  -> policy engine
  -> semantic/keyword router
  -> dry-run or safe GET execution
  -> audit log
  -> metrics summary

Quick Start

Install locally:

pip install -e .[dev]

Inspect a spec:

mcpgen inspect --from examples/jsonplaceholder.openapi.yaml

Generate a FastAPI server:

mcpgen generate --from examples/jsonplaceholder.openapi.yaml --mode fastapi --output generated_jsonplaceholder

Run it:

cd generated_jsonplaceholder
export API_BASE_URL=https://jsonplaceholder.typicode.com
uvicorn server:app --reload --port 8001

PowerShell:

cd generated_jsonplaceholder
$env:API_BASE_URL = "https://jsonplaceholder.typicode.com"
uvicorn server:app --reload --port 8001

Open:

http://127.0.0.1:8001/
http://127.0.0.1:8001/docs
http://127.0.0.1:8001/tools
http://127.0.0.1:8001/safety
http://127.0.0.1:8001/metrics

Example OpenAPI Input

Demo spec:

examples/jsonplaceholder.openapi.yaml

It includes:

• GET /users
• GET /users/{id}
• GET /posts
• GET /posts/{id}
• POST /posts
• DELETE /posts/{id}

Excerpt:

paths:
  /users/{id}:
    get:
      operationId: getUserById
      summary: Get user by ID
      parameters:
        - name: id
          in: path
          required: true
          schema:
            type: integer

Generated Tool Example

Generated safe tool:

{
  "name": "get_user_by_id",
  "description": "Get user by ID",
  "method": "GET",
  "path": "/users/{id}",
  "risk_level": "low",
  "enabled": true,
  "operation_id": "getUserById",
  "input_schema": {
    "type": "object",
    "properties": {
      "id": {
        "type": "integer",
        "description": "User ID",
        "x-mcpgen-location": "path"
      }
    },
    "required": ["id"]
  }
}

Withheld tools such as create_post and delete_post remain in tools.all.json and are explained in safety_report.json.

FastAPI Demo Commands

From the project root:

mcpgen generate --from examples/jsonplaceholder.openapi.yaml --mode fastapi --output generated_jsonplaceholder
cd generated_jsonplaceholder
export API_BASE_URL=https://jsonplaceholder.typicode.com
uvicorn server:app --reload --port 8001

PowerShell:

mcpgen generate --from examples/jsonplaceholder.openapi.yaml --mode fastapi --output generated_jsonplaceholder
cd generated_jsonplaceholder
$env:API_BASE_URL = "https://jsonplaceholder.typicode.com"
uvicorn server:app --reload --port 8001

List exposed safe tools:

curl http://127.0.0.1:8001/tools

Route tools by query:

curl -X POST http://127.0.0.1:8001/tools \
  -H "Content-Type: application/json" \
  -d "{\"query\":\"get user by id\"}"

PowerShell equivalent:

Invoke-RestMethod -Method Post http://127.0.0.1:8001/tools `
  -ContentType "application/json" `
  -Body '{"query":"get user by id"}'

Dry-run a safe tool:

curl -X POST http://127.0.0.1:8001/tools/get_user_by_id/dry-run \
  -H "Content-Type: application/json" \
  -d "{\"inputs\":{\"id\":1}}"

Execute a safe GET tool:

curl -X POST http://127.0.0.1:8001/execute \
  -H "Content-Type: application/json" \
  -d "{\"tool_name\":\"get_user_by_id\",\"params\":{\"id\":1}}"

PowerShell equivalent:

Invoke-RestMethod -Method Post http://127.0.0.1:8001/execute `
  -ContentType "application/json" `
  -Body '{"tool_name":"get_user_by_id","params":{"id":1}}'

Show blocked POST behavior:

curl -X POST http://127.0.0.1:8001/tools/create_post/dry-run \
  -H "Content-Type: application/json" \
  -d "{\"inputs\":{\"title\":\"Hello\",\"body\":\"Demo\",\"userId\":1}}"

Show blocked DELETE behavior:

curl -X POST http://127.0.0.1:8001/tools/delete_post/dry-run \
  -H "Content-Type: application/json" \
  -d "{\"inputs\":{\"id\":1}}"

Show audit log:

cat logs/audit.log

PowerShell equivalent:

Get-Content logs\audit.log

Show metrics:

curl http://127.0.0.1:8001/metrics

PowerShell equivalent:

Invoke-RestMethod http://127.0.0.1:8001/metrics

MCP Mode

Generate an MCP-style stdio server:

mcpgen generate --from examples/jsonplaceholder.openapi.yaml --mode mcp --output generated_jsonplaceholder_mcp

Run:

cd generated_jsonplaceholder_mcp
export API_BASE_URL=https://jsonplaceholder.typicode.com
python server.py

PowerShell:

cd generated_jsonplaceholder_mcp
$env:API_BASE_URL = "https://jsonplaceholder.typicode.com"
python server.py

Example tools/list JSON-RPC input:

{"jsonrpc":"2.0","id":1,"method":"tools/list"}

Example tools/call dry-run input:

{"jsonrpc":"2.0","id":2,"method":"tools/call","params":{"name":"get_user_by_id","arguments":{"id":1}}}

MCP mode uses the same tools.json, policy engine, and audit logging as FastAPI mode. In the current MVP, tools/call is dry-run by default. With execution_mode: safe-execute, it can execute only low-risk GET tools.

Semantic Tool Routing

MCPGen writes tools.embeddings.json during generation and uses it when:

routing_mode: semantic

If embeddings are unavailable or semantic ranking fails, MCPGen automatically falls back to keyword routing. You can force keyword routing with:

routing_mode: keyword

Tool text combines the tool name, description, and optional tags. Example:

create_invoice create invoice for customer billing payments

By default, MCPGen uses a deterministic local embedding fallback so demos and tests work without model downloads. To use sentence-transformers, set:

export MCPGEN_EMBEDDING_BACKEND=sentence-transformers

PowerShell:

$env:MCPGEN_EMBEDDING_BACKEND = "sentence-transformers"

Compare routing modes by changing routing_mode in mcpgen.yaml and regenerating the server. Semantic mode ranks by vector similarity; keyword mode ranks by normalized token overlap and includes matched terms.

Safety Model

MCPGen is safe by default:

• Only low-risk GET tools are exposed in tools.json.
• Medium-risk write tools are withheld unless future config explicitly enables them.
• High-risk DELETE tools are always blocked.
• Real execution is restricted to low-risk GET tools.
• Write execution is not implemented.
• Auth is not implemented.

Policy decisions return:

{
  "allowed": false,
  "status": "blocked",
  "reason": "Medium-risk tool is not listed in enabled_tools.",
  "risk_level": "medium",
  "tool_name": "create_post"
}

Audit Logging

Audit logs are JSONL records written to:

logs/audit.log

Config:

audit_enabled: true
audit_log_path: logs/audit.log
routing_mode: semantic

Each event includes:

• timestamp
• tool name
• method
• path
• risk level
• mode
• status
• allowed
• reason
• source
• action

Actions include:

• policy_evaluation
• dry_run
• execution_started
• execution_success
• execution_error
• execution_blocked

Audit is the event trail. It answers what happened, when, and why for each attempt.

Observability Metrics

v0.3.0 adds lightweight aggregate metrics for generated servers. Metrics are stored as JSON at:

logs/metrics.json

Config:

metrics_enabled: true
metrics_path: logs/metrics.json

Metrics track:

• total tool routes
• total policy evaluations
• dry-runs
• execution starts, successes, errors, and blocked attempts
• confirmation-required decisions
• per-tool route, policy, dry-run, execution, success, error, and blocked counts
• average execution latency in milliseconds per tool
• last updated timestamp

FastAPI mode exposes:

GET /metrics
POST /metrics/reset

Example response:

{
  "total_tool_routes": 1,
  "total_policy_evaluations": 2,
  "total_executions": 1,
  "total_execution_success": 1,
  "total_execution_errors": 0,
  "total_execution_blocked": 1,
  "total_dry_runs": 1,
  "total_confirmation_required": 0,
  "per_tool": {
    "get_user_by_id": {
      "routed": 1,
      "policy_allowed": 2,
      "policy_blocked": 0,
      "dry_runs": 1,
      "executions": 1,
      "successes": 1,
      "errors": 0,
      "blocked": 0,
      "average_execution_latency_ms": 42.5
    }
  },
  "last_updated": "2026-05-05T12:00:00+00:00"
}

Metrics are MVP-level and file-based. They are useful for local demos and development visibility, but they are not a replacement for production telemetry systems.

Auth Passthrough

v0.4.0 adds safe upstream authentication support for generated servers. Secrets are never written into generated files, audit logs, metrics, or responses.

Default config:

auth:
  mode: none
  api_key_env: API_KEY
  api_key_header: X-API-Key

mode: none

No auth headers are sent upstream.

auth:
  mode: none

mode: bearer_passthrough

FastAPI mode can forward an incoming Authorization header to the upstream API only when it starts with Bearer .

auth:
  mode: bearer_passthrough

Example request:

curl -X POST http://127.0.0.1:8001/execute \
  -H "Content-Type: application/json" \
  -H "Authorization: Bearer $TOKEN" \
  -d "{\"tool_name\":\"get_user_by_id\",\"params\":{\"id\":1}}"

PowerShell:

$env:TOKEN = "your-token"
Invoke-RestMethod -Method Post http://127.0.0.1:8001/execute `
  -ContentType "application/json" `
  -Headers @{ Authorization = "Bearer $env:TOKEN" } `
  -Body '{"tool_name":"get_user_by_id","params":{"id":1}}'

MCP stdio mode does not have HTTP headers. For bearer_passthrough, provide explicit auth metadata in tools/call arguments:

{
  "jsonrpc": "2.0",
  "id": 2,
  "method": "tools/call",
  "params": {
    "name": "get_user_by_id",
    "arguments": {
      "id": 1,
      "auth": {
        "authorization": "Bearer your-token"
      }
    }
  }
}

The auth metadata is stripped before tool parameter handling and is not logged.

mode: api_key

API key mode reads a key from an environment variable and injects it into the configured upstream header.

auth:
  mode: api_key
  api_key_env: JSONPLACEHOLDER_API_KEY
  api_key_header: X-API-Key

Bash:

export JSONPLACEHOLDER_API_KEY=your-api-key

PowerShell:

$env:JSONPLACEHOLDER_API_KEY = "your-api-key"

If the environment variable is missing, /execute returns a clear error and does not call the upstream API.

OAuth2 is not implemented yet. It is listed in the roadmap.

Configuration

Default config:

max_tools: 5
allowed_methods:
  - GET
output_dir: generated_mcp_server
api_base_url: https://api.example.com
enabled_tools: []
execution_mode: dry-run
audit_enabled: true
audit_log_path: logs/audit.log
routing_mode: semantic
metrics_enabled: true
metrics_path: logs/metrics.json
auth:
  mode: none
  api_key_env: API_KEY
  api_key_header: X-API-Key

For the JSONPlaceholder demo, set:

api_base_url: https://jsonplaceholder.typicode.com

Current Limitations

• This is a production-oriented MVP, not a production-ready framework.
• Auth support is limited to bearer passthrough and API key header injection.
• No OAuth2 flow yet.
• No write execution.
• No confirmation workflow UI.
• No vector database or embedding cache optimization.
• No rate limiting.
• No database-backed audit sink.
• No production telemetry backend.
• MCP mode uses a minimal stdio scaffold if the official Python MCP SDK is unavailable.

Roadmap

• Official MCP SDK integration
• Auth and secret management
• OAuth2 support
• Confirmation workflow for enabled medium-risk tools
• Rate limiting
• Request/response validation
• Better OpenAPI schema support
• Pluggable audit sinks
• Better semantic routing models and embedding cache optimization
• Deployment templates
