Mlir

MCP (Model Context Protocol) server for MLIR (Multi-Level Intermediate Representation) manipulation. This server enables AI assistants like Claude to parse, generate, transform, and analyze MLIR code through a standardized protocol.

Features

MCP Tools

The server provides 9 MCP tools for MLIR manipulation:

Server Management:

1. ping - Health check endpoint
2. toolchain_info - Get toolchain configuration and tool availability

Parsing & Validation: 3. parse_mlir - Parse MLIR code and extract module information 4. validate_mlir - Validate MLIR syntax and semantics 5. get_module_info - Extract detailed structural information (operations, regions, blocks)

Code Generation: 6. create_function - Generate MLIR functions with custom signatures 7. create_operation - Generate specific MLIR operations 8. generate_from_template - Generate MLIR from predefined templates 9. list_templates - List available generation templates

Configuration

• Zero-configuration setup: Auto-detects MLIR toolchain from common installation locations
• Flexible configuration: Supports .env files and environment variables for custom toolchain paths
• Simple and extensible: Minimal configuration with room for future expansion
• Relaxed validation: Works with minimal MLIR installations (core tools only), with graceful fallback for optional tools

Installation

Prerequisites

• bash or compatible shell
• Python 3.10 or higher
• MLIR toolchain installed (from LLVM project or custom build)
• MLIR Python bindings (optional, but required for parsing tools)

Important: Use the same Python version as your MLIR Python bindings. Check by examining the extension modules:

ls /path/to/mlir/python_packages/mlir_core/mlir/_mlir_libs/
# Look for: _mlir.cpython-311-darwin.so (Python 3.11)
#       or: _mlir.cpython-310-linux.so (Python 3.10)
#                  ^^^^^^^^

From Source

git clone https://github.com/brnorris03/mlir-mcp-server.git
cd mlir-mcp-server

# Create virtual environment with Python version matching your MLIR bindings
# Example: if MLIR was built with Python 3.11
python3.11 -m venv venv
source venv/bin/activate  # On Windows: venv\Scripts\activate

# Install package
pip install -e .

For Development

pip install -e ".[dev]"

MLIR Python Bindings Setup

Automatic Setup (Recommended): Use the MLIR_INSTALLATIONS configuration option (see Configuration section below). The server will automatically configure PYTHONPATH and library paths for you!

Manual Setup (if needed):

# Set MLIR Python bindings path
export PYTHONPATH=/path/to/mlir/python_packages/mlir_core:$PYTHONPATH

# Set library path for MLIR shared libraries
# macOS:
export DYLD_LIBRARY_PATH=/path/to/mlir/lib:$DYLD_LIBRARY_PATH
# Linux:
export LD_LIBRARY_PATH=/path/to/mlir/lib:$LD_LIBRARY_PATH
# Windows:
set PATH=C:\path\to\mlir\bin;%PATH%

Helper Scripts: Use these to run the server/tests:

• ./run_server.sh - Run the server
• ./run_tests.sh - Run tests

Configuration

The MLIR MCP Server uses a simple, flexible configuration system with auto-detection.

Auto-Detection

The server automatically searches for MLIR toolchain in these locations (in order):

1. /opt/ttmlir-toolchain/bin
2. /usr/local/llvm/bin
3. /usr/local/bin
4. /opt/llvm/bin
5. ~/llvm-project/build/bin

If your MLIR toolchain is in one of these locations with mlir-opt present, no configuration is needed!

Simple Configuration

For a single MLIR installation, use MLIR_TOOLCHAIN_PATH:

export MLIR_TOOLCHAIN_PATH=/path/to/llvm/build/bin
python -m mlir_mcp_server

Multiple MLIR Installations

For multiple MLIR projects (e.g., main LLVM + custom dialects), use MLIR_INSTALLATIONS:

# Automatically configures PYTHONPATH, library paths, and tools
export MLIR_INSTALLATIONS=/opt/llvm-build:/opt/custom-project
python -m mlir_mcp_server

Each installation root should contain:

• bin/ - MLIR tools (mlir-opt, custom-opt, etc.)
• lib/ - Shared libraries
• python_packages/mlir_core/ - Python bindings

The server automatically:

• Searches all bin directories for tools
• Adds all Python bindings to sys.path
• Sets platform-specific library paths (DYLD_LIBRARY_PATH on macOS, LD_LIBRARY_PATH on Linux)

Configuration File (.env)

Create a .env file in your project root for persistent configuration.

Option 1: Simple Single Installation

MLIR_TOOLCHAIN_PATH=/path/to/llvm/build/bin

Option 2: Multiple MLIR Installations (Recommended)

Automatically configures tools, Python bindings, and library paths:

# Colon-separated list of MLIR installation roots
# Each should have: bin/, lib/, python_packages/mlir_core/
MLIR_INSTALLATIONS=/path/to/llvm-build:/path/to/custom-mlir-project

# Example with main LLVM + custom "TT" project:
# MLIR_INSTALLATIONS=/opt/llvm:/opt/tt-mlir

This automatically:

• Searches both /opt/llvm/bin and /opt/tt-mlir/bin for tools
• Adds both Python bindings to PYTHONPATH
• Adds both lib directories to LD_LIBRARY_PATH/DYLD_LIBRARY_PATH
• Makes tools like mlir-opt and tt-opt available

No manual PYTHONPATH or LD_LIBRARY_PATH setup needed!

Configuration Priority

The server resolves the toolchain path using this priority (highest to lowest):

1. .env configuration file
2. Environment variables
3. Auto-detected from common locations

Usage with Claude Desktop

Add to your Claude Desktop configuration file:

macOS: ~/Library/Application Support/Claude/claude_desktop_config.json Windows: %APPDATA%\Claude\claude_desktop_config.json Linux: ~/.config/Claude/claude_desktop_config.json

{
  "mcpServers": {
    "mlir": {
      "command": "python",
      "args": ["-m", "mlir_mcp_server"],
      "env": {
        "MLIR_TOOLCHAIN_PATH": "/usr/local/llvm/bin"
      }
    }
  }
}

Note: On Windows, use forward slashes or escaped backslashes in paths (e.g., "C:/LLVM/bin" or "C:\\LLVM\\bin").

If you omit MLIR_TOOLCHAIN_PATH, the server will auto-detect the toolchain.

Running the Server

Standalone

python -m mlir_mcp_server

The server uses stdio transport and is ready to receive MCP requests.

Testing the Installation

After starting the server, you can test it using an MCP client or Claude Desktop. The server provides two basic tools:

• ping: Health check that returns server status
• toolchain_info: Information about the configured MLIR toolchain and available tools

Development

Running Tests

pytest

Code Formatting

black src tests
ruff check src tests

Type Checking

mypy src

Toolchain Validation

The server validates the MLIR toolchain at startup:

• Core tools (required): mlir-opt, mlir-translate
• Optional tools: mlir-reduce, mlir-query, mlir-runner

If core tools are missing, the server exits with an error. If optional tools are missing, warnings are logged and corresponding MCP tools will be disabled when implemented.

Project Status

This project is in active development. Currently implemented:

• ✅ Configuration system with auto-detection
• ✅ Multiple MLIR installations support
• ✅ Automatic Python bindings and library path setup
• ✅ MCP server with 18 tools
• ✅ MLIR parsing tools (parse, validate, get module info)
• ✅ MLIR generation tools (create functions, operations, templates)
• ✅ MLIR transformation tools (apply passes, canonicalize)
• ✅ MLIR analysis tools (count operations, extract functions, analyze operands)
• ✅ MLIR translation tools (MLIR ↔ LLVM IR)
• ✅ Comprehensive test suite (137 tests, 87% coverage)

Coming soon:

• Resource providers for dialect documentation
• Workflow prompts for common MLIR tasks

Contributing

Contributions are welcome! Please feel free to submit a Pull Request.

License

MIT License - see LICENSE for details.

Author

Boyana Norris ([email protected])
