Open Google Image Generator

This project is a Model Context Protocol (MCP) server that exposes Google Cloud Vertex AI and Google GenAI SDK capabilities—Imagen, Gemini, Veo, Lyria, and Chirp models—to MCP-compatible clients. Built with the FastMCP framework.

Current version: 3.1.1 — Full GenAI SDK integration (embed, speech, video analysis, live generation), WebP/AVIF format support, multi-tier model selection, parallel batch generation, sequential pipeline engine, and comprehensive video tools. Service Account JSON auth support, Gemini 3.x text/speech/live models.

Features & Tools

Image Tools

Tool	Description	Backend
tool_generate_image	Text-to-image generation. Supports aspect ratio, negative prompt, seed, watermark, GCS output, and WebP/AVIF output	Imagen 4 (imagen-4.0-fast-generate-001)
tool_edit_image	Mask-based inpaint/outpaint, background swap, product image, and prompt-driven edit. See Edit modes below	Imagen 3 Capability (imagen-3.0-capability-001)
tool_transform_image	Free-form image + text → image transformation: style transfer, scene rewriting, multi-reference composition	Gemini multimodal (gemini-2.5-flash-image)
tool_analyze_image	Multimodal image understanding and Q&A. Supports thinking_level (MINIMAL/LOW/MEDIUM/HIGH) and media_resolution (LOW/MEDIUM/HIGH/ULTRA_HIGH)	Gemini Vision (gemini-2.5-flash)
tool_upscale_image	Upscale low-resolution images	Imagen
tool_remove_background	Remove background via EDIT_MODE_BGSWAP	Imagen
tool_batch_generate	Parallel batch text-to-image generation (up to 10 prompts, max 4 concurrent). balanced tier not supported for batch	Imagen
tool_run_pipeline	Sequential multi-step image processing pipeline (generate → edit → transform → …)	Mixed

Video Tools

Tool	Description	Backend
tool_generate_video	Text-to-video generation. Supports audio_enabled for Veo 3+	Veo (veo-3.1-fast-generate-001)
tool_image_to_video	Animate a still image into video. Supports optional last_frame_path for first+last frame mode	Veo
tool_extend_video	Extend an existing video clip by 4, 6, or 8 seconds	Veo
tool_video_object_edit	Insert or remove an object in a video via operation (insert/remove) and prompt	Veo
tool_analyze_video	Video understanding and Q&A (max 20MB; mp4, mov, avi, webm, mkv)	Gemini GenAI SDK

Audio Tools

Tool	Description	Backend
tool_generate_speech	Text-to-speech with voice selection (Aoede, Charon, Fenrir, Kore, Puck). Supports model_tier (fast/quality). Outputs WAV	Gemini TTS (gemini-3.1-flash-tts-preview / gemini-2.5-pro-preview-tts)
tool_generate_music	Music generation from a text prompt	Lyria 2 / Lyria 3 (GenAI SDK)

GenAI SDK Tools

Tool	Description	Backend
tool_embed	Text embeddings as float vectors	Gemini Embedding (text-embedding-004 on Vertex AI, gemini-embedding-2 / gemini-embedding-001 on Gemini API)
tool_live_generate	Streaming text generation — response is accumulated and returned in full	Gemini Live (gemini-3.1-flash-lite / gemini-3.5-flash / gemini-3.1-flash-live-preview)

Utility Tools

Tool	Description
tool_list_available_models	Live-probes every candidate model in the configured project/location and returns only those that respond (200/400 = reachable, 404 = excluded). Cached for the server process lifetime; pass force_refresh=true to rescan. Also reports available update versions.
tool_upload_file	Register a local file for use as a reference image in subsequent tool calls (e.g. tool_transform_image). Returns a file_uri.

---

Edit modes (tool_edit_image)

edit_mode	What it does	Mask required?
EDIT_MODE_DEFAULT (default)	Prompt-driven full-image edit, no mask	No
EDIT_MODE_INPAINT_INSERTION	Add an object into the masked region	Yes
EDIT_MODE_INPAINT_REMOVAL	Remove content in the masked region	Yes
EDIT_MODE_OUTPAINT	Extend the image beyond its original bounds	Yes
EDIT_MODE_BGSWAP	Swap the background	No
EDIT_MODE_PRODUCT_IMAGE	Product reference styling	No

Use imagen-3.0-capability-001 (default) for all of the above. The legacy imagen-3.0-generate-002 only supports EDIT_MODE_DEFAULT and does not accept a mask.

When to use which "image + text → image" tool

Need	Use
Mask-based inpaint/outpaint/BG-swap with pixel precision	tool_edit_image (Imagen Capability)
"Make it look like X" / style transfer / scene rewriting / multi-reference compositions	tool_transform_image (Gemini multimodal)

Model tiers

Most tools accept a model_tier parameter:

Tier	Description
fast (default)	Lowest latency, lowest cost
balanced	Quality / speed trade-off; routes to Gemini for image generation. Not supported for tool_batch_generate
quality	Higher quality, moderate latency
ultra	Maximum quality (Imagen 4 Ultra / Veo quality models)

Model resolution by tier and tool

Tier	tool_generate_image	tool_transform_image	tool_generate_video
fast	imagen-4.0-fast-generate-001	gemini-2.5-flash-image ¹	veo-3.1-fast-generate-001
balanced	gemini-2.5-flash-image ¹	gemini-2.5-flash-image ¹	veo-3.1-fast-generate-001
quality	imagen-4.0-generate-001	gemini-2.5-pro-image	veo-3.1-generate-001
ultra	imagen-4.0-ultra-generate-001	gemini-2.5-pro-image	veo-3.1-generate-001

GenAI SDK tools (tool_live_generate, tool_analyze_video, tool_generate_speech, tool_embed):

Tier	tool_live_generate / tool_analyze_video	tool_generate_speech	tool_embed
fast	gemini-3.1-flash-lite ¹	gemini-3.1-flash-tts-preview ¹	gemini-embedding-2 / text-embedding-004 ²
balanced	gemini-3.5-flash ¹	—	—
quality	gemini-2.5-pro	gemini-2.5-pro-preview-tts	—

¹ Requires GOOGLE_CLOUD_API_KEY (Gemini API endpoint). Verified working as of June 2026 per Gemini API Models docs. ² gemini-embedding-2 / gemini-embedding-001 are used when GOOGLE_CLOUD_API_KEY is set; text-embedding-004 is used with Vertex AI ADC.

---

Model availability: Vertex AI vs. Gemini API

Google exposes models through two separate endpoints with different model catalogs:

Endpoint	Auth	Image models available	Text/speech models available
Vertex AI (aiplatform.googleapis.com)	ADC / Service Account	gemini-2.5-flash-image, gemini-2.5-pro-image	gemini-2.5-pro/flash/flash-lite
Gemini API (generativelanguage.googleapis.com)	GOOGLE_CLOUD_API_KEY	gemini-3.1-flash-image, gemini-3-pro-image ³	gemini-3.5-flash, gemini-3.1-flash-lite, gemini-3.1-pro-preview

³ Why gemini-3.1-flash-image and gemini-3-pro-image are not currently usable: tool_transform_image and the balanced generate tier call Vertex AI's :generateContent endpoint with an OAuth token. As of June 2026, Google has not yet published these models to the Vertex AI publisher catalog — requesting them returns HTTP 404 regardless of project or region. They are listed in the Gemini API catalog and are reachable only via API key (generativelanguage.googleapis.com). The image transformation backend currently uses Vertex AI, so it cannot use them until Google makes them available there. This server will be updated automatically once they appear.

Sources:

• Gemini API model catalog: https://ai.google.dev/gemini-api/docs/models.md.txt
• Vertex AI model catalog: https://docs.cloud.google.com/gemini-enterprise-agent-platform/models/google-models.md.txt
• Vertex AI available models (live probe): run tool_list_available_models in your project

Output formats

tool_generate_image, tool_edit_image, tool_transform_image, and tool_upscale_image accept a save_format / output_format parameter:

Format	Notes
PNG (default)	Lossless
JPEG	Smaller files, lossy. compression_quality (0-100, default 85) applies only to JPEG
WEBP	Modern lossless/lossy, wide browser support
AVIF	Best compression, requires Pillow>=10

---

Error handling

All tools return a uniform error shape:

{
  "success": false,
  "error": {
    "code": 404,
    "model": "gemini-9.9-nonexistent",
    "endpoint": ":generateContent",
    "message": "Publisher Model `...` is not found.",
    "hint": "Model '...' not found in project '...' / location '...'. Try: gemini-2.5-flash-image.",
    "docs_url": "https://docs.cloud.google.com/...",
    "log_path": ".../logs/vertex_ai_mcp.log",
    "duration_s": 0.42
  }
}

HTTP code	What you'll see in error.hint
400	Vertex's parameter-validation message verbatim
401	"Run gcloud auth application-default login and retry."
403	IAM role hint (roles/aiplatform.user) + Vertex AI API enablement check
404	Live alternatives from the probe cache (tool_list_available_models)
429	Retry after N (from Retry-After header) + quota-increase pointer
500/502/503/504	"Safe to retry once"
TIMEOUT	After 90s — suggests a -fast- variant
VALIDATION	Client-side validation failure (mask missing, file not found, etc.); no HTTP call is made

Full request/response logs are written to logs/vertex_ai_mcp.log.

Resources & Prompts

• Local Resources (local://outputs/{filename}): Generated and processed media files are exposed as MCP resources for seamless display in MCP clients (Claude Desktop, Cursor, etc.).
• Pre-built Prompts: Includes specialized prompt templates for character_design, logo_concept, and UI_UX_mockup.

---

Prerequisites & Resources

1. Python 3.9 or newer
2. Google Cloud Account with an active project
3. Vertex AI API enabled in your project
4. Google Cloud CLI (gcloud) installed and configured

For GenAI SDK tools (tool_embed, tool_analyze_video, tool_generate_speech, tool_live_generate, tool_generate_music), you additionally need one of:

• A Cloud API Key (GOOGLE_CLOUD_API_KEY) — created in GCP Console, uses your existing GCP billing. Enables newer models like gemini-3.5-flash. (Recommended)
• A Gemini API key (GOOGLE_GENAI_API_KEY) — from AI Studio, separate billing.
• Vertex AI ADC — set GOOGLE_GENAI_BACKEND=vertexai, uses gcloud auth application-default login.
• Service Account JSON (GOOGLE_APPLICATION_CREDENTIALS) — see below.

Cloud API Key setup: Run gcloud services enable generativelanguage.googleapis.com apikeys.googleapis.com then gcloud services api-keys create --display-name="GeminiKey". The key string appears in the command output — copy it directly to .env.

---

Installation & Setup

Option A: Install from PyPI

pip install open-google-image-generator-mcp

Option B: Clone the Repository

git clone https://github.com/miracorhan/OpenGoogleImageGeneratorMCP.git
cd OpenGoogleImageGeneratorMCP
pip install -r requirements.txt

Authentication

Choose one of the following methods:

Option A — User account (interactive login):

gcloud auth application-default login

Opens a browser. Use an account that has access to your Google Cloud project.

Option B — Service Account JSON key:

# Download key: GCP Console → IAM & Admin → Service Accounts → Keys → Add Key → JSON
# Required role: Vertex AI User (roles/aiplatform.user)

Set in .env:

GOOGLE_APPLICATION_CREDENTIALS=C:\path\to\service-account-key.json

Both vertex_ai_tools (Imagen, Veo, Lyria) and genai_tools (embed, speech, video analysis, live) pick up the SA JSON automatically. No gcloud CLI required when using a service account key.

Environment Configuration

Create a .env file in the project root:

# Required
GOOGLE_CLOUD_PROJECT=your-google-cloud-project-id
GOOGLE_CLOUD_LOCATION=us-central1

# Output directory for generated media
DEFAULT_OUTPUT_DIR=./outputs

# --- GenAI SDK (for embed, speech, live, music, video-analysis tools) ---
# Option A: Cloud API Key (recommended — uses GCP billing, enables gemini-3.5-flash)
# Create: gcloud services enable generativelanguage.googleapis.com apikeys.googleapis.com
#         gcloud services api-keys create --display-name="GeminiKey"
GOOGLE_CLOUD_API_KEY=AIza...

# Option B: Gemini API key (AI Studio, separate billing, free tier available)
# GOOGLE_GENAI_BACKEND=gemini_api
# GOOGLE_GENAI_API_KEY=AIza...

# Option C: Vertex AI ADC (no key needed, uses gcloud auth application-default login)
# GOOGLE_GENAI_BACKEND=vertexai

# Option D: Service Account JSON key (no gcloud CLI required)
# Download: GCP Console → IAM & Admin → Service Accounts → Keys → Add Key → JSON
# Required role: Vertex AI User (roles/aiplatform.user)
# GOOGLE_APPLICATION_CREDENTIALS=C:\path\to\service-account-key.json

# --- Advanced Vertex AI Authentication (Optional) ---
# Direct OAuth 2.0 Access Token
# GOOGLE_ACCESS_TOKEN=ya29.a0AfB_by...

# Service Account Impersonation
# IMPERSONATE_SERVICE_ACCOUNT=your-service-account@your-project.iam.gserviceaccount.com

---

Usage

Running as a Standalone Script

python mcp_server.py

Integrating with MCP Clients

For Claude Desktop (claude_desktop_config.json):

{
  "mcpServers": {
    "OpenGoogleImageGenerator": {
      "command": "python",
      "args": ["/absolute/path/to/OpenGoogleImageGeneratorMCP/mcp_server.py"],
      "env": {
        "GOOGLE_CLOUD_PROJECT": "your-google-cloud-project-id",
        "GOOGLE_CLOUD_LOCATION": "us-central1",
        "GOOGLE_GENAI_API_KEY": "AIza..."
      }
    }
  }
}

Replace /absolute/path/to/your/... with the actual path, and use the correct Python executable if using a virtual environment.

Example prompts

• "Generate an image of a futuristic city at sunset."
• "Edit this banner — add a glowing cyan halo around the logo." (tool_edit_image, EDIT_MODE_DEFAULT)
• "Transform this photo into a hand-drawn pencil sketch." (tool_transform_image)
• "Remove the background from the image I just generated."
• "Analyze this image and tell me what objects are present."
• "Generate 8 product shots in parallel with different backgrounds." (tool_batch_generate)
• "Run a pipeline: generate → remove background → upscale." (tool_run_pipeline)
• "Convert this text to speech using the Kore voice." (tool_generate_speech)
• "Generate a 30-second ambient music track." (tool_generate_music)
• "Embed this sentence for semantic search." (tool_embed)
• "Animate this product photo into a 5-second video." (tool_image_to_video)
• "Generate a video of a sunset with audio." (tool_generate_video, audio_enabled=true)

---

Troubleshooting

Symptom	Cause	Fix
RefreshError / "Reauthentication needed"	ADC token expired	gcloud auth application-default login or switch to SA JSON
available: {} from tool_list_available_models	Same ADC expiry, probe skipped	Re-authenticate (above)
403 PERMISSION_DENIED with SA JSON	Service account missing role	Grant roles/aiplatform.user to the service account
FileNotFoundError for SA JSON	Wrong path in GOOGLE_APPLICATION_CREDENTIALS	Use an absolute path; forward slashes or escaped backslashes
401 UNAUTHENTICATED with GOOGLE_CLOUD_API_KEY	Key used with Vertex AI endpoint (rejects keys)	Ensure GOOGLE_GENAI_BACKEND is not set to vertexai when using a Cloud API key
403 PERMISSION_DENIED — "Gemini API has not been used"	generativelanguage.googleapis.com not enabled	gcloud services enable generativelanguage.googleapis.com
400 INVALID_ARGUMENT — "API key not valid" even with a brand-new key	Google's key-validation error is identical whether the key is dead or generativelanguage.googleapis.com just isn't enabled on that project — the message doesn't distinguish the two	Confirm with gcloud services list --project=YOUR_PROJECT --filter="config.name:generativelanguage.googleapis.com"; if missing, gcloud services enable generativelanguage.googleapis.com --project=YOUR_PROJECT and allow a few minutes for propagation before retrying
403 PERMISSION_DENIED — "API Keys API disabled"	apikeys.googleapis.com blocked by org policy	gcloud services enable apikeys.googleapis.com
tool_generate_speech / tool_embed / tool_live_generate / tool_analyze_video return 404 NOT_FOUND under GOOGLE_GENAI_BACKEND=vertexai	The TTS-preview, live-preview, and embedding-preview models used by these tools are not published to the Vertex AI publisher catalog — Vertex AI/ADC is not a usable fallback for them, unlike image models	Use GOOGLE_CLOUD_API_KEY or GOOGLE_GENAI_API_KEY (Gemini API endpoint) for these four tools specifically
Worried a GenAI SDK call will charge your Cloud Billing / free-trial credit	Once billing is enabled on a project, the Gemini API free tier is gone entirely for that project — every call becomes billable from the first token, and some promotional/free-trial credits explicitly exclude Gemini API usage regardless	For risk-free testing, create a separate GCP project with no billing account attached at all and generate its AI Studio key there (GOOGLE_GENAI_API_KEY); verify with gcloud billing projects describe YOUR_PROJECT → billingEnabled: false. Keep your billed project for Vertex AI (Imagen/Veo/Lyria) only
Edited .env but the exact same auth error keeps happening	config.py loads .env once at process start and genai_tools._genai_client is cached for the process lifetime — editing the file does not affect an already-running server	Reconnect the MCP server (/mcp → reconnect, or restart the client) after any .env change
404 NOT_FOUND for text-embedding-004	Vertex AI embedding model not available on Gemini API endpoint	Set GOOGLE_CLOUD_API_KEY (auto-selects gemini-embedding-2) or use ADC
404 NOT_FOUND for gemini-3.1-flash-image or gemini-3-pro-image	These models are Gemini API only — not yet on Vertex AI	Use gemini-2.5-flash-image / gemini-2.5-pro-image for transform, or wait for Vertex AI availability
404 NOT_FOUND for a model	Model not available in your project/region	Run tool_list_available_models and pick from available list
gcloud api-keys command not found	Wrong command prefix	Use gcloud services api-keys list/create/delete

Security: The Cloud API Key string appears in plaintext in gcloud services api-keys create output. Copy it directly to .env — never paste it into a chat, commit, or log. Revoke a leaked key immediately with gcloud services api-keys delete KEY_ID.

---

Author & License

• Developer: Mirac Orhan ([email protected])
• License: MIT License (Open Source — Free for everyone to use, modify, and distribute)
