Pylon

Exposes VS Code terminals and IDE features to AI coding agents (Claude Code, Gemini, Cursor, etc.) via a local MCP server. Supports multiple VS Code windows simultaneously through a hub/satellite session model.

Zero dependencies. No proxy. One HTTP endpoint.

Architecture

AI Agent (Claude Code / Gemini / any MCP client)
         │  HTTP POST /mcp
         ▼
   Hub (port 27681)  ◄── session registry
         │
         │  HTTP forward (session_id routing)
         ▼
   AgentServer A (port 27691)   ← Window A
   AgentServer B (port 27692)   ← Window B
   AgentServer C (port 27693)   ← Window C

Every VS Code window runs its own internal AgentServer (port 27691+). The first window to open also starts the Hub on port 27681 — the single MCP endpoint. Subsequent windows register as satellites and send heartbeats. If the hub closes, a satellite auto-promotes.

Installation

1. Build & install the extension

npm run compile
npm install -g @vscode/vsce
vsce package
code --install-extension pylon-mcp-0.5.0.vsix

2. Add MCP config to your AI agent

The MCP endpoint is always http://127.0.0.1:27681/mcp.

Claude Code (~/.claude.json or via CLI):

{
  "mcpServers": {
    "pylon": {
      "type": "http",
      "url": "http://127.0.0.1:27681/mcp"
    }
  }
}

claude mcp add --transport http pylon http://127.0.0.1:27681/mcp

Gemini / other agents: use the same URL in their respective MCP config.

3. That's it

The extension auto-starts when VS Code opens. The status bar shows the current role:

• ⬡ Pylon Hub: myproject — this window owns the hub
• ◎ Pylon: myproject — satellite connected to hub

Available Tools

Terminal Tools

Tool	Description
terminal_list_sessions	Call first. Lists all connected VS Code windows with their session IDs.
terminal_list	List open terminals. Without session_id: all sessions. With session_id: that window only.
terminal_run	Execute a command and capture output (requires shell integration). Returns the moment the command actually ends via shell execution events. Default timeout 300s. Refuses if the target terminal is already running a command. Streams live output via progress notifications when the MCP client provides _meta.progressToken.
terminal_send_text	Send text/keystrokes to a terminal (\x03 = Ctrl+C, \x04 = Ctrl+D).
terminal_read_output	Read buffered terminal output (works on all terminals, no shell integration needed).
terminal_clear_buffer	Clear the output buffer for a terminal.
terminal_wait	Wait for the current (or recently-completed) execution in a terminal to finish, returning output and exit code. Supports progressive check-ins via repeated calls with shorter timeouts.

IDE Tools

Tool	Description
get_diagnostics	Get VS Code diagnostics (TypeScript errors, ESLint warnings, etc.) from all open files or a specific file. Filter by file path or severity level.
get_document_symbols	Get the symbol outline of a file (functions, classes, methods, variables) without reading it. Massive token savings for codebase exploration.
get_references	Find all references/usages of a symbol across the workspace. Critical for understanding blast radius before refactoring.
rename_symbol	LSP-powered rename that updates all references, imports, and type annotations across the workspace.
run_command	Execute any VS Code command by ID. Universal escape hatch — format documents, organize imports, toggle settings, and anything else VS Code can do.

Editor Tools

Tool	Description
open_file	Open a file in the editor and jump to a specific line or highlight a range. The human sees the file appear — use to draw attention to code.
format_document	Format a file using the configured formatter (Prettier, ESLint, etc.) and save. Call after editing to ensure consistent style.
organize_imports	Remove unused imports, sort remaining imports, and save. Call after refactoring to clean up stale imports.
fix_all	Apply all auto-fixable diagnostics (ESLint fixes, missing semicolons, etc.) and save.
save_all	Save all open files with unsaved changes.
find_in_files	Open the workspace search panel with a query. Supports regex, file include/exclude globs, and find-and-replace.
get_hover_info	Get type information, documentation, and signatures for a symbol at a position — what you'd see hovering in VS Code.

Debug Tools

Tool	Description
debug_breakpoints	Add, remove, list, or clear breakpoints. Works without an active debug session. Supports conditional breakpoints and logpoints.
debug_start	Start a debug session by launch.json config name or inline config object. Falls back to the default configuration.
debug_stop	Stop the active debug session or all sessions. Optionally clear breakpoints on stop.
debug_state	Full snapshot of current debug state — threads, call stacks, scopes, and variables in one call. No need to chain requests.
debug_control	Control execution: continue, pause, step over/into/out, restart, or evaluate expressions in the debug context.
debug_console_output	Read debug console output (console.log, stderr, debugger messages). Captures DAP output events not available via terminal tools.

All tools accept an optional session_id parameter to target a specific VS Code window.

Diagnostics Example

Agent calls: get_diagnostics(severity="error", session_id="frontend")
→ 3 diagnostic(s):
→
→ src/app.ts:42:5 Error [ts]: Property 'foo' does not exist on type 'Bar'.
→ src/utils.ts:10:12 Error [ts]: Cannot find name 'response'.
→ src/index.ts:3:1 Error [eslint]: 'React' must be in scope when using JSX.

No need to run tsc or eslint manually — diagnostics come directly from VS Code's language services in real time.

Multi-Window / Multi-Agent Usage

Each VS Code workspace is automatically identified by its folder name as a session ID.

An AI agent should call terminal_list_sessions at the start of a conversation to discover available sessions, identify its own workspace, and use that session_id for all subsequent calls. The tool descriptions instruct agents to do this automatically — no manual configuration required.

Example flow:

Agent calls: terminal_list_sessions
→ [hub]       session="frontend"  agent=http://127.0.0.1:27691
→ [satellite] session="backend"   agent=http://127.0.0.1:27692

Agent in "backend" workspace then uses:
  terminal_run(command="npm run dev", session_id="backend")
  terminal_read_output(session_id="backend", lines=50)
  get_diagnostics(session_id="backend", severity="error")

Hub Failover

If the hub window closes:

1. Satellites detect the missing heartbeat within ~5 seconds
2. The first satellite to respond claims port 27681 and becomes the new hub
3. Other satellites re-register with the new hub automatically

Shell Integration Setup

terminal_run requires VS Code shell integration to be active. Shell integration provides command boundary tracking and output capture via OSC 633 sequences.

Check status: Command Palette → Pylon: Diagnose Shell Integration Shows shellIntegration=YES/NO and cwd for each terminal. If cwd=undefined despite YES, the shell isn't sourcing the integration script.

Per-shell setup

PowerShell — works automatically, no setup needed.

WSL / bash — add to ~/.bashrc:

. "$(code --locate-shell-integration-path bash)"

zsh — add to ~/.zshrc:

. "$(code --locate-shell-integration-path zsh)"

fish — add to ~/.config/fish/config.fish:

source (code --locate-shell-integration-path fish)

CMD — not supported natively. Install Clink for CMD shell integration support.

After adding the script, close and reopen the terminal. Run the diagnose command to confirm cwd is no longer undefined.

If PowerShell blocks profile scripts

Set-ExecutionPolicy -ExecutionPolicy RemoteSigned -Scope CurrentUser

Output Buffering

Terminal output is buffered via VS Code's shell integration events (onDidStartTerminalShellExecution). Shell integration is required for buffering — terminals without it will show no buffered output.

terminal_run executes a command and returns its output inline. terminal_read_output reads the accumulated buffer from all previous commands in that terminal session.

Settings

Setting	Default	Description
pylon.port	27681	Hub port — must match the URL in your AI agent's MCP config
pylon.autoStart	true	Auto-start on VS Code launch
pylon.outputBufferLines	2000	Max lines kept per terminal buffer
pylon.disabledTools	[]	Tool names to hide from AI agents (blocklist)

Ports

Port	Role
27681 (configurable)	Hub — the registered MCP endpoint
27691–27700	AgentServers — one per VS Code window (auto-assigned)

Tool Access Control

Control which tools AI agents can use. All tools are enabled by default.

Visual picker: Command Palette → Pylon: Configure Tool Access — multi-select grouped by category (Terminal, IDE, Editor, Debug).

Manual: Add tool names to pylon.disabledTools in settings:

{
  "pylon.disabledTools": ["debug_start", "rename_symbol", "run_command"]
}

Disabled tools are hidden from tools/list and rejected on tools/call. Changes take effect immediately on the next agent request.

Security

• All servers bind to 127.0.0.1 only — no network exposure
• No authentication — intended for local development use only
• Request bodies capped at 1 MB
