Scanner Extension

A Burp Suite extension for security-testing Model Context Protocol servers.

Discovers MCP tools, resources, resource templates, and prompts, builds JSON-RPC 2.0 requests with fuzzable insertion points, and runs them through Burp's active and passive scanners.

Requires Burp Suite Professional. Every check is driven by Burp's Scanner (active and passive audits), which is not present in Burp Community Edition. The extension loads in Community but cannot scan — discovery may work, but no audit checks will run. Burp Collaborator (also Professional-only) is additionally required for the out-of-band RCE check.

Features

• Transports: Streamable HTTP and SSE (with a local proxy that lets Burp's scanner consume text/event-stream).
• Auth: None, Bearer token, custom header, and OAuth 2.1 (PKCE + dynamic client registration, RFC 8414 / RFC 9728 discovery).
• Active checks: unauthenticated tool discovery, auth bypass, hidden methods, resource path traversal, OAuth token validation, DNS rebinding, OAuth metadata SSRF, DCR misconfiguration, OAuth consent-page reflected XSS, tool-argument path traversal, tool-argument RCE (Collaborator-backed).
• Content checks: scans discovered metadata for leaked secrets (AWS, GitHub, Slack, Stripe, GCP, JWT, SSH/PGP private keys, etc.) and unsafe icon URLs.

Aimed at MCP server operators auditing their own deployments.

Build

./gradlew shadowJar

Output: build/libs/mcp-server-scanner-extension-0.1.0-all.jar.

Requires Java 17.

Install

In Burp: Extensions → Installed → Add → Java, then select the fat JAR above.

Open the MCP Server Scanner tab, configure the server endpoint and auth, and connect.

Test server

A deliberately-vulnerable MCP server lives under test-server/ (uv-managed, Python 3.11+). Use it to exercise checks end-to-end:

cd test-server
uv run server.py

Development

./gradlew test                                    # run all tests
./gradlew test --tests McpRequestDetectorTest     # single class
./gradlew dependencies --write-locks              # regenerate lockfile

See CLAUDE.md for the architecture overview.

Threat model and scope

Use this extension only on MCP servers you own or have written authorization to test.

Scans are intrusive: they send malformed JSON-RPC requests, fuzz tool arguments (which may invoke side-effectful tools on the target server), trigger Burp Collaborator out-of-band interactions, and may briefly stall the target server under load.

This tool is designed for MCP server operators auditing their own deployments. It is not designed for opportunistic scans against MCP servers you do not control.

Known limitations

• Burp Suite Professional required: every check runs through Burp's Scanner (active/passive audits), which Community Edition does not include. In Community the extension loads and can connect/discover, but no scan checks will run. There is no Community-compatible mode.
• Collaborator-backed checks: within Professional, McpActiveToolArgumentRceCheck additionally requires Burp Collaborator for out-of-band detection. It silently degrades and produces no findings if Collaborator is unavailable.
• SSE proxy port: the local SSE proxy binds to an ephemeral loopback port. Firewall or network policies that block loopback traffic will break SSE-transport scans.
• OAuth callback port: the OAuth callback listener defaults to an ephemeral port (port 0). If your authorization server requires strict redirect-URI pre-registration, set a fixed callback port in the OAuth section before initiating the flow.
• Project file sensitivity: tool toggles and OAuth credentials are persisted in the Burp project file. Treat the project file as sensitive and restrict access accordingly.
• Auth-bypass check on SSE transport: on SSE, per-request message POSTs are correlated to the already-opened SSE stream by the endpoint URL rather than by a per-request auth header, so the auth-bypass probe cannot send a fully unauthenticated request the way it does on Streamable HTTP. On SSE the check demonstrates that a tool executes within an already-authenticated session; it does not by itself prove that per-request authentication is absent. The auth-bypass check is fully reliable on Streamable HTTP transport.

Troubleshooting

OAuth 401 loops — usually a clock-skew or audience-mismatch issue. Verify that Mcp-Session-Id is round-tripping through the proxy and that the token audience matches the resource server's expected value.

SSE handshake hangs — confirm the local proxy port is reachable from Burp's scanner. Check the Logger sub-tab for proxy startup errors or connection failures.

tools/list returns empty — the server may require Mcp-Session-Id from a prior initialize handshake. The extension performs this automatically, but a malformed initialize response (non-JSON body or missing protocolVersion) will leave the session unset and subsequent requests will fail silently.

JAR loads but no tab appears — open Burp's Extender output panel and look for a stack trace. The most common causes are a Java version mismatch (requires Java 17+) or a conflicting dependency already loaded by another extension.
