Forward Networks

Version 3.0.0

Forward MCP is an open-source server that provides a set of tools and APIs for interacting with Forward Networks' platform. It enables automation, analysis, and integration with network data using the Model Context Protocol (MCP).

Features

• Exposes 54 Forward Networks tools via the MCP protocol, plus 6 workflow prompts and a network-context resource
• Built on the official MCP Go SDK (protocol revision 2025-06-18, negotiated with older clients)
• Tool behavior annotations (readOnlyHint, destructiveHint, idempotentHint) so clients can distinguish queries from destructive operations
• Schema-enforced input validation with LLM-friendly error messages
• Supports prompt workflows and contextual resources
• Instance lock protection prevents multiple server instances
• Bloomsearch integration for efficient handling of large NQE results, with automatic bloom filter generation and persistent indexes
• Semantic cache and knowledge-graph memory system for query results
• Designed for easy integration and automation

What's New in 3.0.0

Migrated to the official MCP Go SDK

The server now uses github.com/modelcontextprotocol/go-sdk (v1.6.1), replacing the unmaintained metoro-io/mcp-golang library:

• Protocol currency: initialize handshake reports protocol revision 2025-06-18 and negotiates with clients on older revisions (previously pinned to 2024-11-05).
• Populated serverInfo and instructions: clients now see the server name, version, and usage guidance during initialization.
• Tool annotations: every tool declares its behavior — read-only (e.g. list_networks), additive (e.g. create_entity), or destructive (e.g. delete_snapshot) — enabling better client confirmation UX.
• Enforced input validation: tool arguments are validated against their JSON schemas before handlers run; invalid input returns a tool execution error the model can self-correct from. Tools that support the set_default_network fallback accept an omitted network_id.
• Cursor pagination for tool/prompt/resource lists, per the MCP spec.

Forward API client validated against the official OpenAPI spec

The client in internal/forward was audited against https://docs.fwd.app/latest/api/spec/complete.json and brought into conformance:

• Network/Snapshot timestamps decode as RFC3339 strings (createdAt, processedAt); network descriptions map to the API's note field
• Device pagination uses the correct skip parameter (previously offset, which the API silently ignored)
• NQE query options use the spec's single sortBy object and itemFormat field; diff results read totalNumRows
• Single path search decodes the spec's response shape (previously returned empty results)
• Added spec fields: Device.displayName/sourceName/collectionError/processingError/tags, NqeRunResult.totalNumItems, path search srcIpLocationType/unrecognizedValues

High-Level Architecture

• cmd/server/main.go: Entry point for the server. Initializes configuration, logging, and registers tools, prompts, and resources.
• internal/service: Implements the core Forward MCP service logic.
• internal/service/mcp_adapter.go: Adapts service handlers to the official MCP Go SDK and defines per-tool behavior annotations.
• internal/service/bloom_search.go: Bloomsearch integration for large result handling.
• internal/forward: Forward Networks API client (validated against the official OpenAPI spec).
• internal/config: Handles configuration loading (API URL, credentials, etc).
• internal/logger: Provides logging utilities (stderr/file only — stdout is reserved for MCP protocol messages).

Prerequisites

• Go 1.25 or later
• CGO enabled (required for SQLite)
• Access to Forward Networks API (API URL and API Key)

Build Instructions

git clone https://github.com/gaberger/forward-mcp.git
cd forward-mcp
CGO_ENABLED=1 go build -o forward-mcp ./cmd/server
# or: make build

Run Instructions

Set the following environment variables before running:

• FORWARD_API_BASE_URL – Base URL for the Forward Networks API
• FORWARD_API_KEY – Your Forward Networks API key
• FORWARD_API_SECRET - Your Forward Networks API Secret
• FORWARD_DEFAULT_NETWORK_ID – (Optional) Default network ID

Note: TLS 1.3 is enforced for all API connections; certificate verification cannot be disabled.

Bloomsearch Configuration (Optional)

• FORWARD_BLOOM_ENABLED – (Optional, default: true) Enable bloomsearch for large results
• FORWARD_BLOOM_THRESHOLD – (Optional, default: 100) Minimum result size to trigger bloom filter creation
• FORWARD_BLOOM_INDEX_PATH – (Optional, default: data/bloom_indexes) Path for bloom index storage

Instance Lock Configuration (Optional)

• FORWARD_LOCK_DIR – (Optional, default: /tmp) Directory for server instance lock file

Run the server:

./forward-mcp

The server will start and listen for MCP protocol messages via stdio (compatible with Claude Desktop, Claude Code, and other MCP clients).

Bloomsearch Capabilities

Automatic Bloom Filter Generation

• Automatically creates bloom filters for NQE results with >100 items
• Enables fast prefiltering to reduce memory usage and improve search performance
• Persistent storage of bloom indexes for reuse across sessions

Enhanced Search Performance

• Bloom filters provide O(1) lookup time for membership queries
• Reduces memory footprint by only loading relevant data blocks
• Supports complex search patterns with multiple terms

Integration with Existing Systems

• Works seamlessly with the semantic cache and memory system
• Automatically uses bloom filters when available for search operations
• Maintains backward compatibility with existing workflows

Testing

make test-quick        # unit tests
go test -race ./internal/...   # race detector (required before commits)
make test-integration  # live API tests (requires .env with credentials)

Documentation

• See the docs/ folder for troubleshooting, architecture, and advanced guides.
• Instance lock protection guide - docs/INSTANCE_LOCK_GUIDE.md
• New API functions guide - docs/NEW_API_FUNCTIONS.md
• Bloomsearch integration guide and performance optimization tips.

Contributing

Contributions are welcome! Please open issues or pull requests for bug fixes, features, or documentation improvements.

AI Attribution

Portions of this project were generated or assisted by AI tools, including OpenAI GPT-4, Cursor, and Claude. All AI-generated content was reviewed and, where necessary, modified by human contributors.
