Graffiticode

The Graffiticode MCP server connects AI assistants and applications to a growing catalog of domain-specific tools. Each tool is powered by a Graffiticode language — a specialized DSL optimized for a particular task domain. You interact with these languages entirely through natural language: describe what you want to create, and a language-specific AI generates the result.

You never need to learn or write DSL code. The MCP server is the interface.

The server is operated by Artcompiler.

---

How It Works

The Graffiticode MCP server is a thin router. It exposes seven language-agnostic tools that route your natural language requests to language-specific backends. Each backend has deep knowledge of its language's domain and translates your descriptions into working programs.

┌──────────────────────────────────────────────────────────┐
│  Your AI Assistant (Claude, ChatGPT, or any MCP client)  │
│  "Create a concept web assessment about photosynthesis"  │
└──────────────────────────┬───────────────────────────────┘
                           │
                           ▼
┌──────────────────────────────────────────────────────────┐
│  Graffiticode MCP Server (thin router)                   │
│  Tools: create_item, update_item, render_item, get_item, │
│         get_spec, list_languages, get_language_info      │
└──────────────────────────┬───────────────────────────────┘
                           │
                           ▼
┌──────────────────────────────────────────────────────────┐
│  Graffiticode API → Language-specific AI backends        │
│  Discover the current catalog with list_languages        │
└──────────────────────────────────────────────────────────┘

The workflow is the same regardless of language:

1. Discover — Call list_languages to see what's available.
2. Learn — Call get_language_info for details about a specific language.
3. Create — Call create_item with a language ID and a natural language description.
4. Retrieve — Call render_item to display the finished item. (get_item returns raw source and data for programmatic use.)
5. Iterate — Call update_item with a natural language description of what to change, then render_item again.

Generation is asynchronous

create_item and update_item return immediately with an item_id and status: "generating". Generation typically takes 60–110 seconds. Call render_item (or get_item for raw data) to wait for the result — it long-polls until the item is ready (or failed), so you don't need to write your own retry loop.

---

Connecting to the Server

The server speaks the Streamable HTTP transport and is available at:

https://mcp.graffiticode.org/mcp

Claude Desktop

Add via Settings → Connectors with the URL https://mcp.graffiticode.org/mcp. OAuth authentication is handled automatically.

Claude Code

{
  "mcpServers": {
    "graffiticode": {
      "url": "https://mcp.graffiticode.org/mcp"
    }
  }
}

To authenticate with an API key instead of OAuth, add a header:

{
  "mcpServers": {
    "graffiticode": {
      "url": "https://mcp.graffiticode.org/mcp",
      "headers": { "Authorization": "Bearer <your-api-key>" }
    }
  }
}

ChatGPT and Other MCP Clients

Any MCP-compatible client can connect using Streamable HTTP transport at the /mcp endpoint.

Authentication

Authentication is optional. The server supports three modes:

• No auth (free plan) — connect without credentials to try the server. Items you create are scoped to an anonymous workspace, which follows your items across reconnects rather than being tied to a single transport session. You can create items and revise each one up to 5 times; a shared daily allowance applies across all free-plan users. Once an item is ready, the response carries a view_url and a claim_url; opening the claim link and signing in transfers the whole workspace into a real Graffiticode account. Claim links are valid for 24 hours, and unclaimed items are removed after 48 hours.
• OAuth 2.1 (recommended for interactive clients) — the server implements OAuth 2.1 with PKCE. Clients that support MCP OAuth discovery are guided through the flow automatically.
• API key (for programmatic access) — pass your Graffiticode API key as a Bearer token: Authorization: Bearer gc_xxxxx

---

Tools Reference

list_languages

Discover what Graffiticode languages are available. The catalog is dynamic and grows over time.

Name	Type	Required	Description
search	string	No	Match by keyword (e.g. "spreadsheet", "flashcard", "chart")
domain	string	No	Narrow to a domain (e.g. "assessments", "sheets", "diagrams")

Returns each language's id, name, description, domains, and a when_to_use steering note.

Some languages are vendor-gated — they target a specific vendor or platform and say so in when_to_use. Don't select one unless the user actually named that vendor.

---

get_language_info

Get detailed authoring information about a specific language.

Name	Type	Required	Description
language	string	Yes	Language ID (e.g., "L0169")

Returns an inline authoring_guide, supported_item_types, not_for (out-of-scope uses), example_prompts, a spec_url, and a user_guide_resource URI you can read for the full reference.

---

create_item

Create a new item in any Graffiticode language. Describe what you want in natural language — the language-specific AI backend handles everything else.

Name	Type	Required	Description
language	string	Yes	Language ID (e.g., "L0169"). Use list_languages to discover options.
description	string	Yes	Natural language description of what to create.
name	string	No	A friendly name for the item.

Returns an item_id and status: "generating". Call render_item to await and display the result.

What makes a good description? Be specific. Include domain-relevant details, and describe the end result you want rather than implementation details. The language-specific AI understands domain terminology.

---

update_item

Modify an existing item by describing what you want to change. The language is auto-detected from the item.

Name	Type	Required	Description
item_id	string	Yes	The item ID from a previous call.
modification	string	Yes	Natural language description of what to change.

The server maintains conversation history per item, so the language AI has context from previous turns. Like create_item, it returns status: "generating".

---

render_item

Retrieve an item and display it, waiting for generation to finish. This is the preferred user-facing retrieval tool — call it after create_item or update_item.

Name	Type	Required	Description
item_id	string	Yes	The item ID to render.

Long-polls until the item is ready or failed, then returns a compact result (item_id, status, language, name, view_url, and a short summary; free-plan items also carry claim_url/claim_message). The language-private src and data are kept out of the model transcript while still hydrating the interactive widget in Claude.

---

get_item

Retrieve an item's raw src, data, and metadata by its ID. Intended for programmatic clients; for normal use prefer render_item.

Name	Type	Required	Description
item_id	string	Yes	The item ID to retrieve.

Long-polls until the item is ready or failed. Returns the item's data, code, and metadata.

src and data are private to the item's own language. Don't feed them — or a raw item id — into a request for a different language. Use get_spec instead.

---

get_spec

Get a platform-neutral, plain-English description of an item's content.

Name	Type	Required	Description
item_id	string	Yes	The item ID to describe.

This is the only sanctioned way to move content between languages. To turn a spreadsheet into flashcards, call get_spec on the spreadsheet item, then pass that spec (plus your intent) to create_item for the flashcard language.

---

Resources

Beyond tools, the server exposes MCP resources:

Resource	URI	What it is
Language user guide	graffiticode://language/{id}/user-guide	The full authoring reference for a language (markdown).
Agent skills	graffiticode://skills/<id>	Task-oriented skills for agents, discovered at request time from the public graffiticode-skills repo — new skills appear without a redeploy.
Widget	ui://graffiticode/claude-form-widget.html	The MCP Apps widget that renders items inline in Claude. ChatGPT gets no widget — it shows the tool result's text summary and an "Open in Graffiticode" link.

---

Available Languages

The language catalog is dynamic — call list_languages to discover what's currently available, and get_language_info for details on any specific language. Each language has its own specification page, source repository, and usage documentation.

Rather than duplicating a table here that goes stale, start with:

list_languages()                          # everything
list_languages(search: "assessment")      # by keyword
list_languages(domain: "sheets")          # by domain

---

Rendering Items in Your Application

In Claude (web and desktop), items render inline as interactive widgets directly in the chat interface — no setup needed. In ChatGPT the result is shown as a text summary with an "Open in Graffiticode" link.

To embed items in your own application, every Graffiticode language has a corresponding React component published on npm as @graffiticode/<language-id>. Install that package and render its component with the item's data (which get_item returns).

---

Conversation History and Context

The MCP server maintains conversation history for each item. When you call update_item, the server passes context from previous interactions to the language-specific AI, so it understands what you've already created and can make precise modifications.

This means you can work iteratively in a natural conversational style:

1. "Create a concept web about the water cycle with Evaporation at the center"
2. "Add Runoff as a connected concept"
3. "Make it use a dark theme"
4. "Add assessment to all the connected concepts"

Each step builds on the previous ones.

---

Self-Hosting

Build and run

git clone https://github.com/graffiticode/graffiticode-mcp-server.git
cd graffiticode-mcp-server
npm install && npm run build
npm start          # Streamable HTTP server on PORT (default 3001)

Environment Variables

Variable	Default	Description
PORT	3001	HTTP server port
MCP_SERVER_URL	https://mcp.graffiticode.org	Public URL, used for OAuth metadata and discovery
GRAFFITICODE_CONSOLE_URL	https://console.graffiticode.org/api	Console GraphQL endpoint (note the /api suffix)
GRAFFITICODE_CONSOLE_BASE_URL	https://console.graffiticode.org	Console host, used to build claim URLs
GRAFFITICODE_API_URL	https://api.graffiticode.org	API host: language templates and code generation
GRAFFITICODE_APP_URL	https://app.graffiticode.org	App host, used to build item view links
GRAFFITICODE_AUTH_URL	https://auth.graffiticode.org	Auth endpoint
GRAFFITICODE_SKILLS_REPO	graffiticode/graffiticode-skills	Public GitHub repo serving agent skills
GRAFFITICODE_SKILLS_REF	main	Git ref for skill discovery
GRAFFITICODE_SKILLS_TTL_MS	60000	Skill catalog cache TTL
FREE_PLAN_NAMESPACE_SALT	—	HS256 secret for trial-claim JWTs. Must match the console's value. If unset, trial responses still work but omit claim links.
OAUTH_RECONNECT_ENABLED	false	Whether claude.ai/ChatGPT users are told to reconnect their connector and sign in. Off until /oauth/consent accepts the email and wallet sign-ins those users actually have (it is Google-only today), because their connector UIs take no API key and pointing them at an unusable button is worse than saying nothing. Affects trial copy only — never auth itself.
OPENAI_APPS_CHALLENGE_TOKEN	—	Token served verbatim at /.well-known/openai-apps-challenge for OpenAI app-directory domain verification. Set only during submission; the route 404s while unset.
INTERNAL_API_KEY	—	Sent as X-Internal-API-Key to the auth service

Deployment

Deployed to Google Cloud Run (mcp-service, us-central1), fronted by Cloudflare:

npm run gcp:build    # build + deploy via Cloud Build
npm run gcp:logs     # tail logs

---

Support

• Email: [email protected]
• Community: forum.graffiticode.org
• Bug reports: GitHub Issues
• About: mcp.graffiticode.org/about
• Privacy policy: mcp.graffiticode.org/privacy
• Terms of service: mcp.graffiticode.org/terms

---

Source Code

The MCP server is open source under the MIT license, copyright Artcompiler.

• Repository: github.com/graffiticode/graffiticode-mcp-server
• Skills: github.com/graffiticode/graffiticode-skills

All Graffiticode languages are accessed through the natural language interface provided by this MCP server or the Graffiticode console at console.graffiticode.org. Direct code authoring is neither required nor recommended.
